gauge | 12g,14g,16g and 7.2,6.2multi-gauge; |
knitting width | 52" |
knitting speed | controlled by ac servo motor with 24 sections speed optional, max 1.2m/s; |
knitting system | single carriage with double systems,single carriage with three systems; |
knitting function | knit, miss, tuck, transfer, pointelle, intarsia, jacquard, hide,or apparent shaping and other regular patterns. |
racking system | controlled by ac servo motor racking within 2 inches and with fine micro adjustable function. |
encoder | advanced encoder adopted. |
transfer cam | the transfer cam is compose designed,single or double cam system all can trans an other cam system for knitting which will achieve to high production efficiency knit. |
stitch density | controlled by stepping motor,24 sections density selectable,adjustable scope supported by subdivision technology:0-650, the length of knitwear piece can be accurately controlled. |
sinker system | controlled by stepping motor, adjustable to different knitwear ,achieve various results of narrowing and widening. |
comb device | choose close u type compose needle hook. |
clip and cutter(c series) | including 4 clips and 2 cutters,controlled by 6 motors separately.program command can proceed simultaneously or separately to further increase efficiency and reduce waste of yarn. |
take down roller | computerized, controlled by stepping motor,24 levels selection of tension with adjustable scope:0-100. |
yarn feeder | 2x8 yarn feeders on both sides of 1 guide rail of 4, switchover on any position of needle bed (special intarsia yarn feeders optional). |
protection system | the machine will automatically alarm if yarn-breaking, knots floating, rewind, end of knitting, fail of racking, needle jack crash, error programming occur, also with safety auto-lock protection device. |
control system | 1,lcd touch screen, graphical interface. usb and network compatible, with expanded memory of up to 1g. a great amount of patterns can be stored and mobilized for use at any time as per production requirements. 2,monitoring display: various operating parameters can be displayed and can be adjusted anytime when the machine is running, making operations as convenient and time-saving as possible. 3,design system and control system (softwares) are easy to update for free. 4,multi-language operating system:there are chinese, english and arabic versions. languages can be switched according to customer requirements. |
power | single-phase 220v,adopt advanced cmos technology enabling memorizing at the instant of power outages and restoring of knitting thereafter. |
